Small Scale Peanut Screw Oil Presser Mustard Sesame Oil 100 Kg / H Automatic

Small Scale Peanut Screw Oil Presser Mustard Sesame Oil 100 Kg / H Automatic

small scale peanut screw oil presser

mustard sesame oil machine

100 kg/H Automatic Screw Oil Press

Place of Origin:

China

Brand Name:

Henan Lewin

Certification:

CE certification

Model Number:

6YL-70

Contact Us

Request A Quote
Product Details
After-sales Service Provided:
Video Technical Support
Type:
Cold & Hot Pressing Machine
Voltage:
380v/CUSTOMIZED
Automatic Grade:
Automatic
Dimension(l*w*h):
1.7*1.2*1.5M
Material:
SS Materials Body 316 Stainless Steel Screw And Chamber
Raw Material:
Soybean, Various Kinds Of Oil Seeds, Sunflower, Soybean Prickly Pear Seed Oil Extraction Machine
Power(w):
4kw
Warranty:
One Year
Capacity:
50-100 Kg/h
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
$3760 per set
Packaging Details
Standard wooden case packing
Delivery Time
5-8 working days
Payment Terms
T/T, L/C, Western Union, MoneyGram
Supply Ability
100 sets per month
Product Description

screw oil presse machine



Introduction

1.Characteristic
Automatic spiral oil press is mainly composed of electric control, automatic heating, adjustment, transmission and vacuum oil filter components.

2. Principle and Structure:
Oil press machine is to separate the oil from oil bearing materials by the pressing power which comes from the change of chamber volume, drive from screw worm, resistance of curve teeth at press rings and extrusion friction between oil materials. Under the big pressure created in press chamber, the oil can be discharged from gap of press bars and oil trough of press rings. Either big scale and small scale of oil press machine, they have similar theories in screw expeller pressing. Because the screw type oil press machine is mainly used by extrusion theory, so it is also called as oil extruder or oil extrusion process.



Parameter of Castor oil extraction machine

We have different models to meet your request.
According to your requirements, we can also customize for you.


Model Dimension (mm) Weight Power Vacuum power Rotary speed Capacity(kg/h)
6YL-70 1700*1200*1500mm 780kg 4kw 1 lkw 60-100 50-250
6YL-120 2000*1600*2700 1500kg 15kw 1.1kw 100-130 120-160
6YL-130 2150*1600*2700 1600kg 22kw 1.1kw 100-130 180-300
6YL-130(A) 2600*1600*2700 1650kg 18.5kw 1.1kw 100-130 160-280
6YL-150 2550*1800*2700 1800kg 30kw 2.2kw 100-130 220-450
6YL-160 2650*1900*2700 1900kg 30kw 2.2kw 100-130 300-600
6YL-180 2700*2000*2700 1980kg 37kw 2.2kw 100-130 400-750
6YL-220 2920*1900*2700 2000kg 30kw 2.2kw 100-130 400-800
6YL-230 2820*1900*2700 2100kg 37kw 2.2kw 100-130 500-1000



Small Scale Peanut Screw Oil Presser Mustard Sesame Oil 100 Kg / H Automatic 0

Small Scale Peanut Screw Oil Presser Mustard Sesame Oil 100 Kg / H Automatic 1


3. Application


Small Scale Peanut Screw Oil Presser Mustard Sesame Oil 100 Kg / H Automatic 2

Suitable for rapeseed, peanut, soybean, sunflower, rapeseed, sesame, sesame seed, tea seed, walnut, olive, corn germ, rice bran, tea seed, safflower seed, seeds of hippophae rhamnoides and so on.

Package and Delivery:

1. Standard export wooden case package.
2. Customized.
