Place of Origin:
Henan province, china
Brand Name:
Lewin
Certification:
CE ISO
Model Number:
6YY-230A
Contact Us
Video
Information
1. The sesame oil press can heat, squeeze and filter at the same time, and realize automatic control. One person can operate 3-4 machines at the same time.
2. The material can be heated before heating to increase the oil yield
Theory
The working principle is that the when the oil material is put into the assembly of the press boring, then it being driven up by the oil cylinder piston, oil will be outflow from the gap of press boring,and then pass the oil drip pan to the drum for oil storage.
parameters
| Model | 6YY-185 | 6YY-230A | 6YY-250 | 6YY-300 | 6YY-335 |
| Weight | 550kg | 924kg | 1070kg | 1600kg | 1750kg |
| vacuum Power | 1.1kw | 1.1kw | 1.1kw | 2.2kw | 2.2kw |
| 3phase | 2.2kw | 2.2kw | 2.2kw | 4.0kw | 4.8kw |
| Working pressure | 60MPa | 60MPa | 60MPa | 60MPa | 60MPa |
| Capacity (Kg/h) | 4kg/batch | 8.5kg/batch | 11kg/batch | 16kg/batch | 20kg/batch |
| Dimension(mm) |
600*880*1150 |
670*950*1460
|
710*950*1560
|
1000*1100*1660
|
1100*1240*1730
|
Seeds application of hydraulic oil making machine
This machine can squeeze rapeseed, cottonseed, soybean, peanut, linseed, palm, coconut shell, olive fruit, castor, sesame, sunflower, rice bran, corn germ, walnut, almond, evening primrose, pine nut, animal skin, clay And all oil crops, the residual oil rate is less than 5%.
If you want to process other special raw material, please cantact us to ensure.
Selling points
(1) High oil yield, pure oil, no filtration.
(2) The oil is squeezed once, the speed is fast, and the labor intensity is small.
(3) Electromechanical integrated design, small footprint and easy operation.
(4) Fast purification, stable and durable performance.
(5) Professional manufacturer.
This is a flow chart for pressing sesame seeds. It is for your reference only. The sesame seeds after roasting are pressed and pressed to obtain healthy edible oil.
Please contact us if you have any questions.
Simple operation
Our service
Provide quality service
1.Professional engineer
Our professional engineer will test the machine in each step.
2.Specialist manufacture
Every machine carefully adjusted before shipment.
3.After-service
The equipment guarantee period is one year, During guarantee period, the seller will provide maintenance free service.(Except the breakdown and destroy caused by person and force majeure)
Packing and shipping
We have in enough stock and can arrange shipping for you as soon as possible.
