Cold Press Industrial Oil Press Machine peanut Oil Extracting For Oil Mill

Cold Press Industrial Oil Press Machine peanut Oil Extracting For Oil Mill

cold press expeller machine

hydraulic oil extractor

electric oil press machine

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Use For:
Make Oil
Cold Press And Hot Press
Raw Material:
4 Kg/batch
Wooden Case
HS Code:
Alloy And Military Dance Steel
Place Of Use:
Oil Factory Or Thers
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
wooden case
Delivery Time
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100 sets per month
Product Description

cold press soybean oil extracting machine for oil mill factory




1.Safety and durability

1). Motor cover: It can protect the motor service life and safety of people.

2). Internal temperature control parts: It can release the pressure automatically when the working pressure higher than 60Mpa.

3). Large screw: This part can protect the user and machine safety.

4). Pressure release valve: It will release the pressure when over the working pressure.


High oil yield


1). Internal temperature control parts can solve the problem of low oil yield in winter.

2). The oil line is precise, it will filter the residue so can get more oil.

3). Working pressure is 60Mpa is higher than others, it can press raw material cleaner .

4). Solid piston can provide stronger power to press raw material.


Hydraulic oil press machine parameters


Model Pressure Power(3 phases) Capacity(kg/batch) Weight(kg) Dimension(mm)
6YY-185 60mpa 1.1kw 4 590 600*880*1150
6YY-230A 60mpa 1.1kw 8.5 924 670*950*1460
6YY-230B 60mpa 1.1kw 9.5 950 670*950*1560
6YY-250 60mpa 1.1kw 11 1070 710*950*1560
6YY-270 60mpa 2.2kw 13.5 1230 750*1010*1640
6YY-300 60mpa 2.2kw 16 1600 1000*1100*1660
6YY-335 60mpa 2.2kw 20 1750 1100*1240*1730
6YY-355 60mpa 3.0kw 23 2350




Diversity of materials and ways of extracting oil


1)There are two ways to press oil: cold press and hot press.


Cold Press Industrial Oil Press Machine peanut Oil Extracting For Oil Mill 0



2)Applicable to oil producing crops of various seeds, peanuts, soybeans, olives, etc. Common oil extracting materials are as follows:


Cold Press Industrial Oil Press Machine peanut Oil Extracting For Oil Mill 1



  • This hydraulic oil press machine is the most advanced equipment and takes up less area. Its material mainly electroplate.
  • It is economic and environmental protection, stable and durable. This machine adopts automatic control system, hydraulic pressure control system and temperature control system.
  • It has high pressure, high yield oil and easy to operate. This machine can work continuously for 24 hours. It can squeeze 4-23 kilogram per batch, the time of pressing is 8-15 minutes. The oil is pure and fragrant.
  • The pressure of our machine is 60Mpa, higher than other machine(the normal is 45Mpa to 55Mpa), provide higher oil yield.
  • The column material is military steel, very strong, extend the service life.



Cold Press Industrial Oil Press Machine peanut Oil Extracting For Oil Mill 2


Our service:


Service before sale
1.Professionally and patiently introduction, details pictures and working video to show machine.
2.Enter our factory to visit the machine and teach the machine operation method face to face.
3.Accept the raw materials sent by the customer for machine testing

Service on sale
1.Installation:quality and quantity guaranteed;completion of hand over.
2.Acceptance: acceptance test;accepted deliverables.
3.Technical training:on-site installation and products training;operation skills training;maintenance training;centralized technical training.
Service after sale
1.Technical service:long time technical service.
2.Accessories supplying:supplying spare parts with cost price.
3.24 hours online to solve any problem.




Our company's machines not only have a good market and reputation in China, but also have great sales and praise abroad.


Cold Press Industrial Oil Press Machine peanut Oil Extracting For Oil Mill 3
