Automatic Sesame Industrial Oil Press Machine With Simple Operation

Automatic Sesame Industrial Oil Press Machine With Simple Operation

cold press expeller machine

hydraulic oil extractor

Place of Origin:

Henan , China

Brand Name:

Lewin

Certification:

ISO CE

Model Number:

6YY- 335

Contact Us

Request A Quote
Product Details
Name:
Hydraulic Oil Extraction Machine
Model:
6YY - 335
Raw Material:
Many Kinds Of Oil Seeds
Voltage:
380V
Weight:
1750kg
Working Pressure:
60 Mpa
Keywords:
Walnut Oil Mill Machine
Oil Cake Diameter:
335 Mm
Motor Power:
4.8 / 2.2 KW
Oil Rate:
98%
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiation
Packaging Details
Wooden case package / Customized
Delivery Time
7-10 working days
Payment Terms
T/T, D/A, D/P, L/C, Western Union, MoneyGram
Supply Ability
100 sets per month
Product Description

Widely usage automatic sesame oil making machine with simple operation



Cold oil making machine


I. Our production

The oil press machine is our new and original product, it is suitable for cold pressing and hot pressing of anything containing oil,such as olives, sesame , flax seed, peanut kernel, Jasmine Oil,Pumpkin seeds, Walnut Kernel,Chili oil, rape seeds, etc. We believe this machinery can spread out quickly in overseas.It saves more space than traditional oil press and can be operated easily and conveniently. What's more, it is multi-functional.

Automatic Sesame Industrial Oil Press Machine With Simple Operation 0
Automatic Sesame Industrial Oil Press Machine With Simple Operation 1

Parameter of 6YY-335

Model 6YY-335

Production capacity(kg/batch)

20
Working pressure 60 Mpa
Weight (kg) 1750
Voltage 380V

Power (3 /single phase)

4.8 / 2.2 KW

Dimension(m)

1.1*1.24*1.73
Oil cake diameter 335mm
Oil rate 98%























 Main features:

1.Space-saving, small size, small footprint. Besides, the oil cake can be reused as fertilizer

2. Simple structure, easy to operate. (It only has three parts: the body of the machinery,electrical control cabinet ,hydraulic pump station .and the electrical control cabinet only has three buttons what is easy to control.)

3.Quality assurance, high oil rate.(The thinner cake compaction,the higher oil rate.)



Automatic Sesame Industrial Oil Press Machine With Simple Operation 2Automatic Sesame Industrial Oil Press Machine With Simple Operation 3



II. Detail introduction



Operation :



1.Open the top lid, put the bottom plate and filter cloth, and then put the material,Open the hydraulic press switch.



2. Put the steel plate and filter cloth, cover the lid,Start pressing the material.


3.Observe the oil outlet of the oil, the oil from the oil line seepage and from the oil outlet, when the oil is not pressed, close the press switch, this process takes about 3-5min.Turn off the press switch, open the top cover, open the switch again, so that the material barrels rise.


4.Turn off the switch, Take out the filter cloth and the steel plate, take out the residue cake, turn off the electromagnetic valve.

Automatic Sesame Industrial Oil Press Machine With Simple Operation 4Automatic Sesame Industrial Oil Press Machine With Simple Operation 5


III. Our factory


Automatic Sesame Industrial Oil Press Machine With Simple Operation 6
Automatic Sesame Industrial Oil Press Machine With Simple Operation 7



IV. Service

We have professional service for you, includes pre-sale service and after-sale service.

1. Pre- sale service:

We offer 7*24 hours online service, we can reply you quickly,
You can visit our factory at any time,
We can provide the operation and other videos,
We can test the machine according to your need.

2. After sale service:
1). The equipment guarantee period is one year, During guarantee period, the seller will provide maintenance free service.(Except the breakdown and destroy caused by person and force majeure)
2). After receiving the inquiry for repairing the engineer of sell party will solve by phone and email, if necessary the engineer will go to solve the problem on the spot, the buyer should pay daily salary $100, also pay technical visa cost, round trip tickets, rooms and meals.
3). During the quality guarantee period, if it is the quality problem (except easily damaged parts), the cost for maintenance and replace will be borne by sellers.
4). During guarantee period, the seller will provide service of with compensation as follows:
(1)The damage caused by person and force majeure;
(2)The damage caused by improper operating;
(3)The damage caused by reforming, decomposing assembling.
5). Paid service will be provided for the long term after guarantee period.

Automatic Sesame Industrial Oil Press Machine With Simple Operation 8



V. FAQ



Q: What about your package?

A: We use strong wooden case pakage to ensure the safety of our machine.



Q: How about delivery?

A: Generally we delivery the machine within 7-10 working days after receipt the deposit.



Q: What do you support the MOQ?

A: MOQ is 1 set.



Q: How long is your warranty?

A: We offer 1 year warranty.
