60MPa High Pressure Sesame Oil Press Machine / Cold Press Oil Extraction Machine

Minimum Order Quantity : 1 set Price : Negotiation
Packaging Details : Wooden case with film Delivery Time : 5-7working days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 100 sets per month
Place of Origin: Henan province, china Brand Name: Lewin
Certification: CE ISO Model Number: 6YY-230B

Detail Information

Keyword: Hydraulic Oil Making Machine Material: Alloy Steel
Weight: 950kg Dimension: 670*950*1560 Mm
Capacity: 9.5 Kg/batch Advantage: Full Automatic
Voltage: 380V
High Light:

cold press expeller machine

,

hydraulic oil extractor

Product Description

60MPa high pressure sesame oil pressers cold press oil extraction machine



Theory of hydraulic oil press machine

The working principle is that the when the oil material is put into the assembly of the press boring, then it being driven up by the oil cylinder piston, oil will be outflow from the gap of press boring,and then pass the oil drip pan to the drum for oil storage.

Brief information

1. This is a kind of hydraulic oil press machine.
2. Which can press sesame, olive, cocoa beans, walnuts, almonds, and other high oil crops.
3. This machine is very suitable for family using and small scale oil factories.

4. After pressed, the oil is very pure with good smell, can be edible for people directly.
5. Stable and durable performance, replace consumables on time, machine life can be more than ten years.

6. It is made of stainless steel , so the oil can reach the healthy standard. Which is do good to people health.





parameters

Model 6YY-185 6YY-230B 6YY-250 6YY-300 6YY-335
Weight 550kg 950kg 1070kg 1600kg 1750kg
vacuum Power 1.1kw 1.1kw 1.1kw 2.2kw 2.2kw
3phase 2.2kw 2.2kw 2.2kw 4.0kw 4.8kw
Working pressure 60MPa 60MPa 60MPa 60MPa 60MPa
Capacity  4kg/batch 9.5kg/batch 11kg/batch 16kg/batch 20kg/batch
Dimension(mm)

600*880*1150

670*950*1560
710*950*1560
1000*1100*1660
1100*1240*1730



Selling points

1.It has high pressure, the pressure of our machine is 60Mpa, higher than other machine(the normal is 45Mpa to 55Mpa), provide higher oil yield.

2.professional research and development, complete model, advanced manufacturing technology, beautiful appearance.

3.High oil yield, pure oil, no filtration.

4.Fast purification, stable and durable performance.

5.Our core technology to increase the oil yield. Independent and more oil lines design, special treatment technology for the steel to ensure the tank stronger enough.

Seeds application of hydraulic oil making machine

60MPa High Pressure Sesame Oil Press Machine / Cold Press Oil Extraction Machine 0

If you want to process other special raw material, please cantact us to ensure.

Workflow

60MPa High Pressure Sesame Oil Press Machine / Cold Press Oil Extraction Machine 1

Simple operation

60MPa High Pressure Sesame Oil Press Machine / Cold Press Oil Extraction Machine 2

Our service

Provide quality service

1.Professional engineer

Our professional engineer will test the machine in each step.

2.Specialist manufacture

Every machine carefully adjusted before shipment.

3.After-service

The equipment guarantee period is one year, During guarantee period, the seller will provide maintenance free service.(Except the breakdown and destroy caused by person and force majeure)

60MPa High Pressure Sesame Oil Press Machine / Cold Press Oil Extraction Machine 3

Packing and shipping

We have in enough stock and can arrange shipping for you as soon as possible.

60MPa High Pressure Sesame Oil Press Machine / Cold Press Oil Extraction Machine 4

Company information

60MPa High Pressure Sesame Oil Press Machine / Cold Press Oil Extraction Machine 5



Since1998, Henan Lewin Industry Development Co., Ltd was found officially registered under Henan Companies Registry.It is a firm which has the ability for Manufacture,Research&Development, Sale and Export. Our mainproducts are hydraulic oil press machine, spiral oil press machine, the accessory equipment for the oil press machine and other machine.
