High capacity 6YY model oil presser hydraulic oil making machine for healthy oil

Minimum Order Quantity : 1 set Price : Negotiation
Packaging Details : Wooden case with film Delivery Time : 5-7working days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 100 sets per month
Place of Origin: Henan province, china Brand Name: Lewin
Certification: CE ISO Model Number: 6YY-250

Detail Information

Other Name: Hydraulic Oil Extrator Material: Alloy Steel
Weight: 1070kg Dimension: 710*950*1560 Mm
Capacity: 11 Kg/batch Advantage: High Oil Yield
Voltage: 380V
High Light:

cold press expeller machine

,

electric oil press machine

Product Description

High capacity 6YY model oil presser hydraulic oil making machine for healthy oil



Product Information

LEWIN automatic high-speed hydraulic oil press is a new type hydraulic oil press that Combining the characteristics of traditional oil presses, and improving in terms of oil extraction

It is easy to use, easy to operate, and has high oil yield. It is a professional equipment for extracting high oil crops such as sesame, peanut, walnut, almond, pine nut and tea seed.

parameters

Model 6YY-185 6YY-230B 6YY-250 6YY-300 6YY-335
Weight 550kg 950kg 1070kg 1600kg 1750kg
vacuum Power 1.1kw 1.1kw 1.1kw 2.2kw 2.2kw
3phase 2.2kw 2.2kw 2.2kw 4.0kw 4.8kw
Working pressure 60MPa 60MPa 60MPa 60MPa 60MPa
Capacity 4kg/batch 9.5kg/batch 11kg/batch 16kg/batch 20kg/batch
Dimension(mm)

600*880*1150

670*950*1560
710*950*1560
1000*1100*1660
1100*1240*1730

Theory of hydraulic oil press machine

The working principle is that the when the oil material is put into the assembly of the press boring, then it being driven up by the oil cylinder piston, oil will be outflow from the gap of press boring,and then pass the oil drip pan to the drum for oil storage.

Seeds application of hydraulic oil making machine

High capacity 6YY model oil presser hydraulic oil making machine for healthy oil 0

If you want to process other special raw material, please cantact us to ensure.

Workflow

High capacity 6YY model oil presser hydraulic oil making machine for healthy oil 1

This is the operation process diagram of sesame. The sesame after the wok is roasted and dried, and automatically enters the oil press through the wind suction system. Save time and effort and save space. More importantly, the sesame after roasting is full of color and flavor, healthy and pure, and can be eaten directly.

Simple operation

High capacity 6YY model oil presser hydraulic oil making machine for healthy oil 2

Our machines are easy to operate and can be operated by one person. We will provide you with videos to guide you in the installation and operation of the machine.If necessary, we can also arrange an engineer to go to the site to guide.

Our service

Provide quality service

1.Professional engineer

Our professional engineer will test the machine in each step.

2.Specialist manufacture

Every machine carefully adjusted before shipment.

3.After-service

The equipment guarantee period is one year, During guarantee period, the seller will provide maintenance free service.(Except the breakdown and destroy caused by person and force majeure)

High capacity 6YY model oil presser hydraulic oil making machine for healthy oil 3

Packing and shipping

We have in enough stock and can arrange shipping for you as soon as possible.

High capacity 6YY model oil presser hydraulic oil making machine for healthy oil 4

Company information

High capacity 6YY model oil presser hydraulic oil making machine for healthy oil 5

High capacity 6YY model oil presser hydraulic oil making machine for healthy oil 6

Since1998, Henan Lewin Industry Development Co., Ltd was found officially registered under Henan Companies Registry.It is a firm which has the ability for Manufacture,Research&Development, Sale and Export. Our mainproducts are hydraulic oil press machine, spiral oil press machine, the accessory equipment for the oil press machine and other machine.
