Single Phase Industrial Oil Press Machine Easy Operation With High Performance

Minimum Order Quantity : 1 set Price : Negotiation
Packaging Details : Wooden case package / Customized Delivery Time : 7-10 working days
Payment Terms : T/T, D/A, D/P, L/C, Western Union, MoneyGram Supply Ability : 100 sets per month
Place of Origin: Henan , China Brand Name: Lewin
Certification: ISO CE Model Number: 6YY- 230A

Detail Information

Name: Hydraulic Oil Pressing Machine Model: 6YY - 230 A
Usage: Cold & Hot Pressing Suit For: Kinds Of Oil Seeds
Material: Kinds Of Seeds Voltage: 380V
Power: 2.2 Kw / 1.1 Kw Key Word: Almond Oil Making Machine
HS Code: 8479200000 Working Pressure: 60 Mpa
High Light:

cold press expeller machine

,

electric oil press machine

Product Description

I. Production description





Single Phase Industrial Oil Press Machine Easy Operation With High Performance



Our 6YY-230A oil press machine:



1. It can save labor and save cost: only one or two people can operat 4-6 sets machines.
2. Our hydraulic oil press machine adopt physical method to press oil to keep the essence not destroyed.
3. 60Mpa max working pressure offers stronger power to press, increase the oil yield.
4. Specially heating treatment for the steel, makes the machine stronger to bear the high working pressure.

Single Phase Industrial Oil Press Machine Easy Operation With High Performance 0



Appliction range

This machine can cold or hot press various of oil seeds, includes sesame, peanut, castor, walnut, camellia, olive, palm, avocado, sunflower, rapeseed, ect.

Single Phase Industrial Oil Press Machine Easy Operation With High Performance 1





Parameter:

Model 6YY-185 6YY-230A 6YY-230B 6YY-250 6YY-270 6YY-300 6YY-335 6YY-355

Capacity

(kg/batch)

4 8.5 9.5 11 13.5 16 20 23
Working pressure 60Mpa 60Mpa 60Mpa 60Mpa 60Mpa 60Mpa 60Mpa 60Mpa
Weight (kg) 590 924 950 1070 1230 1600 1750 2350

Power

(3 /single phase)

1.1/2.2 kw 1.1/2.2 kw 1.1 /2.2kw 1.1/2.2 kw 2.2/4.0 kw 2.2/4.8 kw 2.2/4.8 kw 3.0/5.0 kw

Package

Size(m)

0.78*1*1.58 0.78*1*1.58 0.78*1*1.68 0.78*1.04*1.71 0.82*1.081*1.75 0.94*1.14*1.81 0.94*1.16*1.8 1.04*1.24*1.92

Capacity

(Kg/24h)

190-260 500-650 600-750 650-780 800-1000 950-1200 1100-1400 1500-2000
Oil cake diameter 185mm 230mm 230mm 250mm 270mm 300mm 335mm 355mm
Residual oil ≤2% ≤2% ≤2% ≤2% ≤2% ≤2% ≤2% ≤2%


















































II. Working Process:



Working principle

This machine is powered by the hydraulic tank that pushs the piston up to squeeze the raw material in the press kettle.

Single Phase Industrial Oil Press Machine Easy Operation With High Performance 2



Workflow:



Single Phase Industrial Oil Press Machine Easy Operation With High Performance 3

Operation step:

Single Phase Industrial Oil Press Machine Easy Operation With High Performance 4



III. Advantages



Single Phase Industrial Oil Press Machine Easy Operation With High Performance 5

Single Phase Industrial Oil Press Machine Easy Operation With High Performance 6






IV. Packing & Delivery

Packing:

1. Standard export wooden case package.

2. Customized.

Delivery:

We can arrange to ship by sea in generally 7-10 working days after receipt the deposit. Also we can offer other shipping method, such as by air, by express, by train and so on. We have many shipping agent to meet different request for the shipping.

Single Phase Industrial Oil Press Machine Easy Operation With High Performance 7


V. Our service

1. Pre-sale service:

We offer different solution for different request and material.

Factory view accepted.

Test machine accepted.

7x24 hours online service.

2. After sale service:

1). The equipment guarantee period is one year, During guarantee period, the seller will provide maintenance free service.(Except the breakdown and destroy caused by person and force majeure)
2). After receiving the inquiry for repairing the engineer of sell party will solve by phone and email, if necessary the engineer will go to solve the problem on the spot, the buyer should pay daily salary $100, also pay technical visa cost, round trip tickets, rooms and meals.
3). During the quality guarantee period, if it is the quality problem (except easily damaged parts), the cost for maintenance and replace will be borne by sellers.
4). During guarantee period, the seller will provide service of with compensation as follows:
(1)The damage caused by person and force majeure;
(2)The damage caused by improper operating;
(3)The damage caused by reforming, decomposing assembling.
5). Paid service will be provided for the long term after guarantee period.

Single Phase Industrial Oil Press Machine Easy Operation With High Performance 8


VI. Our company

Single Phase Industrial Oil Press Machine Easy Operation With High Performance 9

Warehouse:

Single Phase Industrial Oil Press Machine Easy Operation With High Performance 10
