1.1 kw sesame oil pressing machine use alloy material with high pressure
Our 6YY-230A oil press machine:
1. This hydraulic oil press machine adopts automatic control system, hydaulic pressure control system and temperature control system.
2. This machine can work with many kinds of oil seeds well.
3. This machine can work continuously for 24 hours. It can squeeze 8 kilogram per batch, the perssing time is 8-15 minutes.
4. The pressure of our machine is 60Mpa, higher than other machine(the normal is 45Mpa to 55Mpa), provide higher oil yield.
5. The material of this machine is alloy that can make sure the safety.
Appliction range
This machine can cold or hot press various of oil seeds, includes sesame, peanut, castor, walnut, camellia, olive, palm, avocado, sunflower, rapeseed, ect.
Parameter:
| Model | Capacity(kg/batch) | Weight(kg) | Working pressure | power(kw) | Dimension(mm) | oil cake diameter |
| YY-185 | 4 | 590 | 60MPa | 2.2/1.1 | 600*880*1150 | 180mm |
| YY230(A) | 8.5 | 924 | 60MPa | 2.2/1.1 | 670*950*1460 | 230mm |
| YY-230(B) | 9.5 | 950 | 60MPa | 2.2/1.1 | 670*950*1560 | 230mm |
| YY-250 | 11 | 1070 | 60MPa | 2.2/1.1 | 710*950*1560 | 250mm |
| YY-270 | 13.5 | 1230 | 60MPa | 4.0/2.2 | 750*1010*1640 | 270mm |
| YY-300 | 16 | 1600 | 60MPa | 4.0/2.2 | 1000*1100*1660 | 300mm |
| YY-335 | 20 | 1750 | 60MPa | 4.0/2.2 | 1100*1240*1730 | 355mm |
| YY-355 | 23 | 2350 | 60MPa | 5.0/3.0 | 1160*1200*1810 | 355mm |
This machine is powered by the hydraulic tank that pushs the piston up to squeeze the raw material in the press kettle.
Workflow:
Operation step:
Packing:
1. Standard export wooden case package.
2. Customized.
Delivery:
We can arrange to ship by sea in generally 7-10 working days after receipt the deposit. Also we can offer other shipping method, such as by air, by express, by train and so on. We have many shipping agent to meet different request for the shipping.
1. Pre-sale service:
We offer different solution for different request and material.
Factory view accepted.
Test machine accepted.
7x24 hours online service.
2. After sale service:
1). The equipment guarantee period is one year, During guarantee period, the seller will provide maintenance free service.(Except the breakdown and destroy caused by person and force majeure)
2). After receiving the inquiry for repairing the engineer of sell party will solve by phone and email, if necessary the engineer will go to solve the problem on the spot, the buyer should pay daily salary $100, also pay technical visa cost, round trip tickets, rooms and meals.
3). During the quality guarantee period, if it is the quality problem (except easily damaged parts), the cost for maintenance and replace will be borne by sellers.
4). During guarantee period, the seller will provide service of with compensation as follows:
(1)The damage caused by person and force majeure;
(2)The damage caused by improper operating;
(3)The damage caused by reforming, decomposing assembling.
5). Paid service will be provided for the long term after guarantee period.
