60 MPa Domestic Oil Press Machine , High Oil Rate Cooking Oil Processing Machine

60 MPa Domestic Oil Press Machine , High Oil Rate Cooking Oil Processing Machine

cold press expeller machine

electric oil press machine

Place of Origin:

Henan , China

Brand Name:

Lewin

Certification:

ISO CE

Model Number:

6YY- 185

Contact Us

Request A Quote
Product Details
Name:
Hydraulic Oil Making Machine
Model:
6YY - 185
Keyword:
Sunflower Oil Pressing Machine
Usage:
Cold & Hot Pressing
Pressure:
60 MPa
Voltage:
380 V
HS Code:
8479200000
Oil Rate:
98%
Weight:
590 Kg
Shipping:
By Sea
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
Negotiation
Packaging Details
Wooden case package / Customized
Delivery Time
7-10 working days
Payment Terms
T/T, D/A, D/P, L/C, Western Union, MoneyGram
Supply Ability
100 sets per month
Product Description

High oil rate home use oil making machine for sesame with 60Mpa


I. Production description

1. This hydraulic oil press machine adopts automatic control system, hydaulic pressure control system and temperature control system.

2. This machine can work with many kinds of oil seeds well.

3. This machine can work continuously for 24 hours. It can squeeze 4 kilogram per batch, the perssing time is 8-15 minutes.

4. The pressure of our machine is 60Mpa, higher than other machine(the normal is 45Mpa to 55Mpa), provide higher oil yield.

5. The material of this machine is alloy that can make sure the safety.

60 MPa Domestic Oil Press Machine , High Oil Rate Cooking Oil Processing Machine 0



Appliction range

This machine can cold or hot press various of oil seeds, includes sesame, peanut, castor, walnut, camellia, olive, palm, avocado, sunflower, rapeseed, ect.

60 MPa Domestic Oil Press Machine , High Oil Rate Cooking Oil Processing Machine 1

Work principle:

This machine is powered by the hydraulic tank that pushs the piston up to squeeze the raw material in the press kettle.

60 MPa Domestic Oil Press Machine , High Oil Rate Cooking Oil Processing Machine 2



Parameter:

Model 6YY-185 6YY-230A 6YY-230B 6YY-250 6YY-270 6YY-300 6YY-335 6YY-355

Capacity

(kg/batch)

4 8.5 9.5 11 13.5 16 20 23
Working pressure 60Mpa 60Mpa 60Mpa 60Mpa 60Mpa 60Mpa 60Mpa 60Mpa
Weight (kgs) 590 924 950 1070 1230 1600 1750 2350

Power

(3 /single phase)

1.1/2.2 kw 1.1/2.2 kw 1.1 /2.2kw 1.1/2.2 kw 2.2/4.0 kw 2.2/4.8 kw 2.2/4.8 kw 3.0/5.0 kw
Package Size(mm) 780*1000*1580 780*1000*1580 780*1000*1680 780*1040*1710 820*1081*1750 940*1140*1810 940*1160*1800 1040*1240*1920

Capacity

(Kg/24h)

190-260 500-650 600-750 650-780 800-1000 950-1200 1100-1400 1500-2000
Oil cake diameter 185mm 230mm 230mm 250mm 270mm 300mm 335mm 355mm
Residual oil ≤2% ≤2% ≤2% ≤2% ≤2% ≤2% ≤2% ≤2%



















































Workflow:



60 MPa Domestic Oil Press Machine , High Oil Rate Cooking Oil Processing Machine 3


II. Our advantages

60 MPa Domestic Oil Press Machine , High Oil Rate Cooking Oil Processing Machine 4

60 MPa Domestic Oil Press Machine , High Oil Rate Cooking Oil Processing Machine 5

60 MPa Domestic Oil Press Machine , High Oil Rate Cooking Oil Processing Machine 6


III. Our service

1. Pre-sale service:

We offer different solution for different request and material.

Factory view accepted.

Test machine accepted.

7x24 hours online service.

2. After sale service:

1). The equipment guarantee period is one year, During guarantee period, the seller will provide maintenance free service.(Except the breakdown and destroy caused by person and force majeure)
2). After receiving the inquiry for repairing the engineer of sell party will solve by phone and email, if necessary the engineer will go to solve the problem on the spot, the buyer should pay daily salary $100, also pay technical visa cost, round trip tickets, rooms and meals.
3). During the quality guarantee period, if it is the quality problem (except easily damaged parts), the cost for maintenance and replace will be borne by sellers.
4). During guarantee period, the seller will provide service of with compensation as follows:
(1)The damage caused by person and force majeure;
(2)The damage caused by improper operating;
(3)The damage caused by reforming, decomposing assembling.
5). Paid service will be provided for the long term after guarantee period.

60 MPa Domestic Oil Press Machine , High Oil Rate Cooking Oil Processing Machine 7


IV. Packing & Delivery



Packing:

1. Standard export wooden case package.

2. Customized.

Delivery:

We can arrange to ship by sea in generally 7-10 working days after receipt the deposit. Also we can offer other shipping method, such as by air, by express, by train and so on. We have many shipping agent to meet different request for the shipping.

60 MPa Domestic Oil Press Machine , High Oil Rate Cooking Oil Processing Machine 8
