Small Scale Cold And Hot Oil Press Machine Automatic Cooking Oil Presser Cooking Sunflower Oil Press Machine

Small Scale Cold And Hot Oil Press Machine Automatic Cooking Oil Presser Cooking Sunflower Oil Press Machine

Automatic Cooking Sunflower Screw Oil Presser

Screw Oil Press Machine 7.5kw

380V Sunflower Screw Oil Presser

Place of Origin:

China

Brand Name:

Lewin

Certification:

CE/ISO

Model Number:

6YL-70

Contact Us

Request A Quote
Product Details
Model:
6YL-70
Capacity:
50-100kg/h
Power:
7.5kw
Vacuum Power:
1.1kw
Weight:
450kg
Voltage:
220V/380V/optional
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
$3000-$3780 per set
Packaging Details
1.7*1.2*1.65m, packing with film+wooden case
Delivery Time
5-7 days
Payment Terms
L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability
300 set per month
Product Description

Small Scale Cold And Hot Oil Press Machine Automatic Cooking Oil Presser Cooking Sunflower Oil Press Machine

It is a multi-function oil press machine, most oil raw material can be pressed by it, peanut, sunflower, moringa seed, coconut, sesame, cotoon seed, mustard seed, corn, avocado etc., send inquiry to us to geting more details about it, we will make a best solution for you!

Small Scale Cold And Hot Oil Press Machine Automatic Cooking Oil Presser Cooking Sunflower Oil Press Machine 0Small Scale Cold And Hot Oil Press Machine Automatic Cooking Oil Presser Cooking Sunflower Oil Press Machine 1

Specifications of Screw Oil Presser:



Model



6YL-60

6YL-70



6YL-80

Power



3kw

7.5kw



7.5kw

Vacuum power



0.75kw

1.1kw



1.1kw

Voltage



220V/optional

220V/380V/optional



220V/380V/optional

Production capacity



40-70kg/h

50-100kg/h



80-120kg/h

Dimension(mm)



1050*800*1200

1400*1000*1300



1600*1100*1500mm

Wight(kg)



380kgs

450kgs



550kgs





Working Principle:
  • The working principle is that the oil is extruded from the material embryo and discharged from the slots and oil troughs of the strip and circle rows by the continuous pushing of the material embryo in the squeezing chamber and the change of the space volume of the squeezing chamber from large to small, and the oil can be directly eaten in a barrel after deep filtration of the oil tank.






 Functions of Oil Press Machine:
Small Scale Cold And Hot Oil Press Machine Automatic Cooking Oil Presser Cooking Sunflower Oil Press Machine 2

1. It support both cold and hot press, you can choose the pressing way according to your local customs or kind of raw materials.

2. It equipped with vacuum filter system, it is a negative pressure enviroment in the system when it working, crude oil will be sucked into filteration system, through 3 layer filterations, crude oil become pure and clear, final oil after vacuum filter system can reach to edible grade directly, no need use other filterations to process it.

3. 6YL-70 model screw oil presser is the middle model, it is very suitable for new start people of oil business, it is one-time investment and permanent gains, it almost no consumables, only oil filter cloth, it is cheaper, negligible.

4. Use Chinese famous motor brand, high quality motor support longer service life, the machine can continuous work more than 20h.

5. Machine raw material use alloy steel, strong enough to support it working normally.

Shipping and packing:





Small Scale Cold And Hot Oil Press Machine Automatic Cooking Oil Presser Cooking Sunflower Oil Press Machine 3

Service:

Pre-service

1.We will test and adjust before we send the machine, make sure it can be used with confidence after receiving it.

2.We accept the customized model.


After-service:

1). The equipment guarantee period is one year, During guarantee period, the seller will provide maintenance free service.(Except the breakdown and destroy caused by person )

2). After receiving the inquiry for repairing the engineer of sell party will solve by phone and email, if necessary the engineer will go to solve the problem on the spot, the buyer should pay daily salary $100, also pay technical visa cost, round trip tickets, rooms and meals.

3). During the quality guarantee period, if it is the quality problem (except easily damaged parts), the cost for maintenance and replace will be borne by sellers.

4). During guarantee period, the seller will not provide service of with compensation as follows:

(1)The damage caused by person ;

(2)The damage caused by improper operating.

Any interest about screw oil presser contact us!!!!
