Food Grade Cold Press Oil Extraction Machine , Olive Oil Press Machine Large Capacity
Contact Person : Waley Pan
Phone Number : 15617821227
WhatsApp : +8613526696760
Minimum Order Quantity : | 1 set | Price : | Negotiation |
---|---|---|---|
Packaging Details : | Wooden Carton Customization | Delivery Time : | 7-10 working days |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 100 sets per month |
Place of Origin: | Henan Province, China | Brand Name: | Lewin |
---|---|---|---|
Certification: | CE ISO | Model Number: | 6YL-130 |
Detail Information |
|||
Product Name: | Screw Oil Machine | Material: | Alloy Steel |
---|---|---|---|
Advantage: | Cold And Hot Pressing | Weight: | 1.6 Ton |
Oil Material: | Groundnut, Sesame, Olive, Corn. | Voltage: | 380 V/Customized |
Capacity: | 180-300 Kg/h | ||
High Light: | Spiral Peanut Oil Expeller,180 Kg/H Peanut Oil Expeller,Cold Spiral Oil Processing Equipment |
Product Description
Product Information
1. The 6YL series screw press is designed to meet customer requirements for petroleum production.
2. This machine has reasonable design, advanced performance and beautiful appearance.
3. Save time, effort and space.
4. Large processing capacity, high oil yield, pure oil crystals, no foam, no impurities, and can be eaten directly.
5. The L feeding system can realize secondary pressing and extract oil with maximum efficiency.
Operating priciple:
The working principle is that the oil is extruded from the material embryo and discharged from the slots and oil troughs of the strip and circle rows by the continuous pushing of the material embryo in the squeezing chamber and the change of the space volume of the squeezing chamber from large to small, and the oil can be directly eaten in a barrel after deep filtration of the oil tank.
Technical parameters of oil presser:
Model | 6YL-120 | 6YL-130 | 6YL-150 | 6YL-160 | 6YL-180 |
Weight | 1200 kg | 1600 kg | 1800 kg | 1900 kg | 1980 kg |
Vacuum power | 1.1 kw | 1.1 kw | 2.2 kw | 2.2 kw | 2.2 kw |
3phase | 15 kw | 22 kw | 30kw | 30 kw | 37 kw |
Squeezer speed | 100-130 | 100-130 | 100-130 | 100-130 | 100-130 |
Capacity(kg/h) | 120-160 | 180-300 | 220-450 | 300-600 | 400-750 |
Dimension(mm) | 2000*1600*2700 | 2150*1600*2700 | 2550*1800*2700 | 2650*1900*2700 | 2700*2000*2700 |
Detailed images
Parts of high quality oil presser:
Advantages:
1. L feeding system realizes secondary pressing and avoids oil waste.
2. The two feeding systems work together to improve work efficiency.
3. The vacuum oil filtering system can directly obtain edible pure oil.
4. Work uninterrupted 24 hours a day to reduce manual work and improve work efficiency.
Seeds application of screw oil making machine
It is suitable for direct processing of rape, peanut, sunflower seed, sesame, olive and other oil crops. It does not need to be steamed and fried.
If you want to process other special raw material, please cantact us to ensure.
Workflow
Packing & shipping
We use strong wooden case to ensure the safety of your goods in transit.
Our service
Provide quality service
1.Professional engineer
Our professional engineer will test the machine in each step.
2.Before delivery
Every machine carefully adjusted before shipment.
3.After-service
The equipment guarantee period is one year, During guarantee period, the seller will provide maintenance free service.(Except the breakdown and destroy caused by person and force majeure)
