Commercial Screw Oil Press Machine Peanut Oil Press Machine High Efficiency

Commercial Screw Oil Press Machine Peanut Oil Press Machine High Efficiency

cold press oil extractor

small scale oil extraction machine

Place of Origin:

China, Henan

Brand Name:

Lewin

Certification:

ISO CE

Model Number:

6YL-120

Contact Us

Request A Quote
Product Details
Product Name:
Commercial Screw Peanut Oil Press Machine Cold An Hot Press For Oil Plant
Material:
Carbon Steel Stainless Steel
Raw Material:
Kinds Of Seed And Nuts
Appication:
Home/food Shop/oil Plant
Item:
FOB
Color:
Sliver
Press Type:
Screw
Shipping Method:
Sea
Package:
Wooden Case With Film
Delivery Time:
7-15days
Keep Working:
24h
HS Code:
8479200000
Payment & Shipping Terms
Minimum Order Quantity
1 set
Packaging Details
Wooden case with film.
Delivery Time
7-15 days
Payment Terms
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability
50 sets per week
Product Description

commercial screw peanut oil press machine cold an hot press for oil plant

Product description

1. Our screw model oil press machine can do both hot and cold press, protect the quality of the oil.
2. This oil press machine can work with many different oil material and it can be set different temperature for different material, high working efficiency and high oil yield.
3. Vacuum oil filter service the oil press machine well, can get the oil at the food grade level directly.
4. We equipped the L type oil cake feeding system, just need one worker to operate it, save labour and improved the working efficiency.
5. The thickness of the oil cake can be adjusted according to the request.



Model Weight The vacuum power Power Squeezer speed Capacity Dimension
6YL-120 1500kg 1.1kw 15kw 60-100 r/min 120-160 kg/h 2000*1600*2700(mm)

Structure & Direction display

Commercial Screw Oil Press Machine Peanut Oil Press Machine High Efficiency 0

Working principle

Screw oil press machine is specially for cold and hot press. The material are pushed by the press screw and squeezing during the pushing by the different capacity of the press kettle,the oil will discharge from the space of the cage bar or the oil pocket.After the vacuum oil filter,the quality of the oil can be reached to the cooking grade.

Application

Our machine can apply to many kinds of different materials,such as rapeseed,soybean,peanut,flax seed sesame,corn,cottonseed……
Commercial Screw Oil Press Machine Peanut Oil Press Machine High Efficiency 1
* we also offer the testing service for the special materials you offer to us.

Oil & Oil cake
Commercial Screw Oil Press Machine Peanut Oil Press Machine High Efficiency 2
Commercial Screw Oil Press Machine Peanut Oil Press Machine High Efficiency 3

Working process

Commercial Screw Oil Press Machine Peanut Oil Press Machine High Efficiency 4

Details & Advantages

Commercial Screw Oil Press Machine Peanut Oil Press Machine High Efficiency 5

1.The temperature of the machine can be adjusted. The processing system and the filtration system can work at same time.

2.You can adjust the thickness of the oil cake according to your demand.

3.The power of the electric motor is three-phase current,which provides enough power to squeeze the materials.

4.The speed(60-100r/min) of our squeezers is faster than others (40-50r/min),which improves the oil yield.

5.Our spiral squeezer is row-shape,it can squeeze materials roundly,improve the oil yield.

6.If the machine appears that the material cannot enter smoothly during the squeezing,you can press the button of reversal ,which ensures the process smoothly.

7.The gearbox can slow the speed of the squeezer to reduce abrasion of machine.

Our services

Pre-service:

1.Visit our factory
2.Support online guide
3.Accept customer-made

After-sale sevice:

1.Support online guide
2.Exchange Vulnerable Parts for a low price
3.Inquiry about the machine for free

Package & Shipping

We use wooden boxes to pack the machine, which can reduce the wear and tear on the machine, thus protecting the machine. If the customer has their own needs, we can customize the packaging according to the customer's demands.

Commercial Screw Oil Press Machine Peanut Oil Press Machine High Efficiency 6

Company introduction

We use wooden boxes to pack the machine, which can reduce the wear and tear on the machine, thus protecting the machine. If the customer has their own needs, we can customize the packaging according to the customer's demands.
Commercial Screw Oil Press Machine Peanut Oil Press Machine High Efficiency 7

Our customer & Exhibition

Commercial Screw Oil Press Machine Peanut Oil Press Machine High Efficiency 8

Feedback

Commercial Screw Oil Press Machine Peanut Oil Press Machine High Efficiency 9

FAQ

Q:Do you have your own factory?
A:Yes, we have our factory and warehouse.

Q:Could we visit the factory?
A:Yes, welcome to our factory to visit the machine.

Q:Could you send me the sample to me?
A:Yes, we can send you the oil sample squeezed by our machine or send video.

Q: How can I choose the model that suits me?
A:You can tell us your needs, we will recommend the best machine model for you.

Q:How about the oil productivity?
A:According the temperature and the materials you squeeze, there will present different oil productivity.

Q:Which kinds of materials does the machine can squeeze?
A:Generally, all kinds of. In addtion we can test the special material you offer to us for free.

Q:How long does it take to transport?
A:7-15days without special circumstances.
