6YL high capacity oil process machine with screw type for plant seeds

6YL high capacity oil process machine with screw type for plant seeds

Production description

1. The 6YL series screw oil press is designed to meet the requirements of customers for oil production. The machine is reasonable in design, advanced in performance and beautiful in shape. It is suitable for direct processing of rape, peanut, sunflower seed, sesame, olive and other oil crops.

2. It does not need to be steamed and fried. It saves time, labor and space. It has large processing capacity, high oil output rate, crystal and pure oil, no foam and no impurities. The automatic feeding elevator can fully realize production automation.
3. The machine is composed of feeding hopper, gear box, press cage, press screw, row, cake mouth, tip, rack, cylinder, vacuum pump, motor and other components.

4. The working principle is that the oil is extruded from the material embryo and discharged from the slots and oil troughs of the strip and circle rows by the continuous pushing of the material embryo in the squeezing chamber and the change of the space volume of the squeezing chamber from large to small, and the oil can be directly eaten in a barrel after deep filtration of the oil tank.

Parameter:

1.we have different models for you to choose.

2. According to your requirements, we can also customize for you

Main Features

1. Automatic spiral oil presser with vacuum filtration, fast purification and automatic temperature control technology
2. High oil yield, about 3% higher than the average oil press, and easy to install
3. The oil is purity and can be eaten directly after vacuum filtration

screw oil presser can press lots of materials such as: Avocado, Perilla, cocoa bean, Melon seeds etc

Peanut oil  extratcion process:

Detailed Images

This machine mainly includes four parts:
1. Main engine 2. Screw system 3. Electrical system 4. Vacuum pump


The following is the specific introduction:
Main engine includes base,upright,top plate,oil drip pan,nut and etc which is one of the main parts. When the oil material is put into the assembly of the press boring,then it being driven up by the oil cylinder piston ,oil will be outflow from the gap
of press boring,and then pass the oil drip pan to the drum for oil storage
