Place of Origin:
Henan, China
Brand Name:
Lewin
Certification:
ISO
Model Number:
6YL-130
Contact Us
6YL-130screw oil making machine main parameter:
| Model | 6YL-130 |
| Weight | 1600KG |
| Vacuum Power | 1.1KW |
| Main Power | 22KW |
| Squeezer speed | 100-130 |
| Capacity (Kg/h) | 180-300 |
|
Dimension(mm) |
2150*1600*2700 |
When oil press is operating, prepared material enters the chamber from the hopper and then moves forwards by the rotating pressing screw and is pressed. Under the high pressure condition in the chamber, friction between material and screw, between material and chamber will be created, which also creates friction and relative movement among material particles.
On the other hand, root diameter of the pressing screw varies larger from one end to the other. Hence, when rotating, it not only pushes particlesmoving forwards but turns them outwards as well.
Meanwhile, particles adjacent the screw will rotate along with screw's rotating, causing every particle inside the chamber to posses different speed.
Therefore, relative movement among particles creates heat which is necessary during manufacturing because of helping protein change property, damage colloid, increase plasticity, decrease oil's elasticity, resulting in high oil productivity.
Pre-service:
1.we will provide the 24*7 hours best service for you.
2.We accept the customized model.
After-service:
All products are guaranteed to keep in good repaired for one year. During the one year, the seller will provide free maintenance service. (Expect for failures and damage caused by human and force majeure.)
We have 20 years of production experience, we have our own factory warehouse, we can guarantee the quality of the products, and can provide you with multiple machines at one time.
All screw sausage making machines will be kept in standard export wooden case carton ,Which can ensure the machine intact.
Leading time: 1-3 working days
.
