Place of Origin:
Henan province, china
Brand Name:
Lewin
Certification:
CE ISO
Model Number:
6YY-355
Contact Us
Hydraulic oil processing device cold hydraulic oil pressure machinery
Hydraulic oil press theory
The working principle is that the when the oil material is put into the assembly of the press boring, then it being driven up by the oil cylinder piston, oil will be outflow from the gap of press boring,and then pass the oil drip pan to the drum for oil storage.
Basis Description:
1.This machine has the advantages of high pressure, high oil output, compact structure and controllable temperature. In addition, it is not only energy efficient, but also environmentally friendly.
2.The oil press is simple and safe to operate, greatly reducing labor intensity, saving labor and improving work efficiency
It can be widely used to squeeze sesame, soybean, peanut, flax, walnut kernel, tea seed, almond, pine nut and other oils (better peeling effect).
3. If you have special oil material, we can provice testing service for free.
Parameters
Model | 6YY-185 | 6YY-230A | 6YY-250 | 6YY-300 | 6YY-355 |
Weight | 550kg | 924kg | 1070kg | 1600kg | 2350kg |
vacuum Power | 1.1kw | 1.1kw | 1.1kw | 2.2kw | 3.0kw |
3phase | 2.2kw | 2.2kw | 2.2kw | 4.0kw | 5.0kw |
Working pressure | 60MPa | 60MPa | 60MPa | 60MPa | 60MPa |
Capacity | 4kg/batch | 8.5kg/batch | 11kg/batch | 16kg/batch | 23kg/batch |
Dimension(mm) |
600*880*1150 |
670*950*1460
|
710*950*1560
|
1000*1100*1660
|
1160*1200*1810
|
(1) High oil yield, pure oil, no filtration
(2) The oil is squeezed once, the speed is fast, and the labor intensity is smallSeeds application of hydraulic oil making machine
If you want to process other special raw material, please cantact us to ensure.
Simple operation
We will provide you with videos and manuals to help you install and use the machine.
Our service
We have professional engineers to provide you with the best service.
1.Professional engineer
Our professional engineer will test the machine in each step.
2.Specialist manufacture
Every machine carefully adjusted before shipment.
3.After-service
The equipment guarantee period is one year, During guarantee period, the seller will provide maintenance free service.(Except the breakdown and destroy caused by person and force majeure)
Packing and shipping
We have a professional packaging and transportation team to provide you with protection during transportation.
