Squeeze 100r/Min 160Kg/H Rapeseed Screw Oil Press Machine

Squeeze 100r/Min 160Kg/H Rapeseed Screw Oil Press Machine

Rapeseed Screw Oil Press Machine

160Kg/H Screw Oil Press Machine

100r/Min Screw Oil Press Machine

Place of Origin:

China

Brand Name:

Lewin

Certification:

CE ISO

Model Number:

6YL-120

Contact Us

Request A Quote
Product Details
Machine Name:
Screw Oil Press Machine
Model:
6YL-120
Capacity:
120-160 Kg/h
Weight:
1500kg
Power:
15kw
Squeezer Speed:
60-100r/min
After-sales Service Provided:
Engineers Available To Service Machinery Overseas,Online Support,Video Technical Support,Field Installation
Product Name:
Screw Press Oil Expelle,hydraulic Grain Seed Oil Press/cold Almond Oil Press Machine,vegetable Seeds Oil Press,Oli Press Machine
Application:
Oil Production Line,Oil Pressing
Voltage:
220V/380V/Customizible
Payment & Shipping Terms
Minimum Order Quantity
1 set
Packaging Details
Wooden case+ Film packaging
Delivery Time
5-10 days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
300 sets/month
Product Description
6yl120 Cotton Seed Screw Oil Press Machine For Rapeseed And Peanut With 160 Kg/H Capacity



Product Brief:

  1. The material was pushed by the press screw and squeezing during the pushing by the different capacity of the press kettle, the oil will discharge from the space of the cage bar or the oil pocket.

  2. After the vacuum oil filter, the quality of the oil can be reached to the cooking grade.

  3. L type oil cake feeding system equiped, it can improve the working efficiency and save labour.

  4. Big and copper structure motor offer more power to press the raw material.

  5. Our screw oil press machines are equipped two vacuum filter system, they can filter residual from oil, help you get pure and clear oil.

  6. Oil flow from vacuum filter system can reach cooking oil grade, no need other machines to processing it, you can filling it for sell directly.

 Parameter :

Model Weight (kg) The vacuum power (kw)

3 Phase

380V (kw)

Squeezer speed (r/min) Capacity (kg/h) Dimension (mm3)
6YL-120 1500 1.1 15 60-100 120-160 2000*1600*2700
6YL-130 1600 1.1 22 60-100 180-300 2150*1600*2700
6YL-130A 1650 1.1 18.5 60-100 160-280 2600*1600*2700
6YL-150 1800 2.2 30 60-100 220-450 2550*1800*2700
6YL-160 1900 2.2 30 60-100 300-600 2650*1900*2700
6YL-180 1980 2.2 37 60-100 400-750

2700*2000*2700



Materials:
1. Our cold and hot oil press machine can work with different raw materials, such as sunflower , soybean, sesame, rapeseed, peanut, cotton seed, corn germ, walnut, almond etc.

2. For the special oil materials we also support testing service and will send the testing videos for your reference.

Squeeze 100r/Min 160Kg/H Rapeseed Screw Oil Press Machine 0



Advantage:

Squeeze 100r/Min 160Kg/H Rapeseed Screw Oil Press Machine 1



Packing & Delivery:

shipping : 1.We are mechanical products with a high weight, so we recommend sea transportation.

                2.We will meet your needs if you have other requirements for the transportation method.


Packing : Making packing inside is plastic films and out side is fumigation wooden case. Our wooden case is very strong, it can bear long time shipping on the sea; Machine with preservative film, it can stop the salt sea water enter into the machine and make the machine corrosion.
