60 Mpa Working Pressure Walnut Oil Extraction Machine 8 Kg Per Batch Capacity

Product Description

60 Mpa working pressure sesame walnut oil extraction machine oil presser

---

Our machine can press sesame oil, peanut oil, cocoa butter oil, olive oil and etc. It is mainly used to produce edible oil.



1. This hydraulic oil press machine adopts automatic control system, hydaulic pressure control system and temperature control system.



2. This machine can work with many kinds of oil seeds well.



3. This machine can work continuously for 24 hours. It can squeeze 8 kilogram per batch, the perssing time is 8-15 minutes.

4. The pressure of our machine is 60Mpa, higher than other machine(the normal is 45Mpa to 55Mpa), provide higher oil yield.



5. The material of this machine is alloy that can make sure the safety.

Appliction range

This machine can cold or hot press various of oil seeds, includes sesame, peanut, castor, walnut, camellia, olive, palm, avocado, sunflower, rapeseed, ect.

Parameter:

Model	6YY-185	6YY-230A	6YY-230B	6YY-250	6YY-270	6YY-300	6YY-335	6YY-355
Capacity (kg/batch)	4	8.5	9.5	11	13.5	16	20	23
Working pressure	60Mpa	60Mpa	60Mpa	60Mpa	60Mpa	60Mpa	60Mpa	60Mpa
Weight (kg)	590	924	950	1070	1230	1600	1750	2350
Power (3 /single phase)	1.1/2.2 kw	1.1/2.2 kw	1.1 /2.2kw	1.1/2.2 kw	2.2/4.0 kw	2.2/4.8 kw	2.2/4.8 kw	3.0/5.0 kw
Package Size(m)	0.78*1*1.58	0.78*1*1.58	0.78*1*1.68	0.78*1.04*1.71	0.82*1.081*1.75	0.94*1.14*1.81	0.94*1.16*1.8	1.04*1.24*1.92
Capacity (Kg/24h)	190-260	500-650	600-750	650-780	800-1000	950-1200	1100-1400	1500-2000
Oil cake diameter	185mm	230mm	230mm	250mm	270mm	300mm	335mm	355mm
Residual oil	≤2%	≤2%	≤2%	≤2%	≤2%	≤2%	≤2%	≤2%















































---

Work principle:

This machine is powered by the hydraulic tank that pushs the piston up to squeeze the raw material in the press kettle.



Workflow:



Operation step:

---

Our advantages

Features:

1. This machine has the advantages of small volume and less land occupation; the operation is easy to learn, easy to understand, easy to operate, and needs not particular requirements to the operator.



2. This machine can save 50% power compared with stone mill.



3. This machine belongs to hydraulic oil press, and it has many advantages, such as high-pressure, high oil ratio, and the oil of final product is very clean.



4. This machine adopts full automatic control system, and no matter the preheat temperature or the pressure of hydraulic system, it is all automatic control.

---



Packing & Delivery

Packing:

1. Standard export wooden case package.

2. Customized.

Delivery:

We can arrange to ship by sea in generally 7-10 working days after receipt the deposit. Also we can offer other shipping method, such as by air, by express, by train and so on. We have many shipping agent to meet different request for the shipping.

---

Our service

1.Offer the most suitable solution for you.

2. Visiting our factory.

3. Testing machine for you.

4. Always online to help you.

5. Delivery products immediately after receipt tje payment.

6. Change voltage according to your needs.

7. Operation manual, operation video and install video.

---
