Customized Voltage Camellia Oil Manufacturing Machine With Oil Cake Feeding System

Customized Voltage Camellia Oil Manufacturing Machine With Oil Cake Feeding System

cold press expeller machine

hydraulic oil extractor

electric oil press machine

Place of Origin:

Henan

Brand Name:

Lewin

Certification:

ISO

Model Number:

6YL-160

Contact Us

Request A Quote
Product Details
Product Name:
Lewin Factory Supply Camellia Oil Extracting Machine With Oil Cake Feeding System
Type:
Cold & Hot Pressing Machine,tiger Nut Oil Press/ Oil Press Machine/cooking Oil Press Machine
Application:
Oil Production Line,rape Seeds,Screw Oil Expeller,Olive Oil Expeller,sesame
Raw Material:
Rapeseeds,Cottonseed,Corn Germ,Mustard Seed,Flaxseed
Capacity:
300-600kg/h
Voltage:
220V/380V/customized
Squeezer Speed:
60-100 RPM
Power:
30kw
Vacuum Power:
2.2kw
Weight:
1900kg
Condition:
New
Warranty:
One Year
Dimension(l*w*h):
2650*1900*2700mm
After-sales Service Provided:
Video Technical Support/online Support
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiation
Packaging Details
standard export wooden case with film
Delivery Time
5-7 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
300 set per month
Product Description

Lewin factory supply camellia oil extracting machine with oil cake feeding system

Introduction for screw oil press:


Working principle:

Oil press machine is to separate the oil from oil bearing materials by the pressing power which comes from the change of chamber volume, drive from screw worm, resistance of curve teeth at press rings and extrusion friction between oil materials. Under the big pressure created in press chamber, the oil can be discharged from gap of press bars and oil trough of press rings. Either big scale and small scale of oil press machine, they have similar theories in screw expeller pressing. Because the screw type oil press machine is mainly used by extrusion theory, so it is also called as oil extruder or oil extrusion process.



6YL-160 automatic oil presser is advanced peanut, sunflower and other material oil machine, characterized by simple design, easy to operate, high production capacity and high oil output rate. Moreover, this kind of machine can be used for various raw materials, and depending on the oil content of particular crop you are pressing, the machine will extract about 95%-98% oil of it.

Customized Voltage Camellia Oil Manufacturing Machine With Oil Cake Feeding System 0

Parameter:


Model

Dimension (mm)

Weight

Power

Vacuum power

Rotary speed

Capacity(kg/h)

6YL-120

2000*1600*2700

1500kg

15kw

1.1kw

100-130

120-160

6YL-130

2150*1600*2700

1600kg

22kw

1.1kw

100-130

180-300

6YL-130(A)

2600*1600*2700

1650kg

18.5kw

1.1kw

100-130

160-280

6YL-150

2550*1800*2700

1800kg

30kw

2.2kw

100-130

220-450

6YL-160

2650*1900*2700

1900kg

30kw

2.2kw

100-130

300-600

6YL-180

2700*2000*2700

1980kg

37kw

2.2kw

100-130

400-750

1.we have different models for you to choose.

2. According to your requirements, we can also customize for you.



Our high oil yield screw oil presser can press lots of materials such as: Avocado, Perilla, cocoa bean, Melon seeds etc.
If there have no materials of your needs in this picture, you can contact us and we provide a free testing.



Customized Voltage Camellia Oil Manufacturing Machine With Oil Cake Feeding System 1





Customized Voltage Camellia Oil Manufacturing Machine With Oil Cake Feeding System 2     Customized Voltage Camellia Oil Manufacturing Machine With Oil Cake Feeding System 3

                  With feeding machine                                            Screw squeezer



Customized Voltage Camellia Oil Manufacturing Machine With Oil Cake Feeding System 4     Customized Voltage Camellia Oil Manufacturing Machine With Oil Cake Feeding System 5

                        Vacuum motor                                        Oil cake feeding system



Our warehouse:


Customized Voltage Camellia Oil Manufacturing Machine With Oil Cake Feeding System 6

Customized Voltage Camellia Oil Manufacturing Machine With Oil Cake Feeding System 7

We have our own factory and warehouse, so we can guarantee the quality of the oil press machine, if there are any other questions about our oil pressing machine, we can give you a best solution, in addition, We are factory direct sale, cut out the middleman, thus makes the price lowest for our customers. so if you need, please contact us freely!

Our service:


Pre-service:

  • We will test and adjust before we send the oil presser, make sure it can be used with confidence after receiving it.

  • We accept the customized model.


After-service:

  • All products are guaranteed to keep in good repaired for one year. During the one year, the seller will provide free maintenance service. (Expect for failures and damage caused by human and force majeure.)

  • After receiving the inquiry for repairing the engineer of sell party will solve by phone and email. If necessary, the engineer will solve the problem on the spot, the buyer should pay daily salary $100, also pay technical visa cost, round trip tickets, rooms and meals.

Packing & Shipping:


Customized Voltage Camellia Oil Manufacturing Machine With Oil Cake Feeding System 8    Customized Voltage Camellia Oil Manufacturing Machine With Oil Cake Feeding System 9

We use strong wooden case to ensure the safety of your goods in transit.


We don't make bad products, don't produce defective products, zero defect production process, 100 points of quality products, 1% defect = 100% of waste products.

If you are interested in our machine, we will offer you videos of testing the machines.
