Place of Origin:
Nangyang, Henan
Brand Name:
Lewin
Certification:
ISO CE
Model Number:
YY-185
Contact Us
Fully automatic Alloy hydraulic oil making machine with high pressure
Small oil press machine automation operation , low price, widely used in family and small oil factory. This hydraulic oil press machine is suitable for cold pressing or hot pressing many oil seeds , Especially for pressing sesame, olive, avocado, and so on valuable oil seeds. Full automatic hydraulic oil press is a small oil press which is most convenient in operation, highest yield efficiency, as well as least replacement spare parts. Only one hydraulic oil press machine, you could get the better oil and easy to operate.
Our oil presser machine has the following characteristics:
1. It can save labor and save cost: only one or two people can operat 4-6 sets machines.
2. Our hydraulic oil press machine adopt physical method to press oil to keep the essence not destroyed.
3. 60Mpa max working pressure offers stronger power to press, increase the oil yield.
4.Specially heating treatment for the steel, makes the machine stronger to bear the high working pressure.
(1) High oil yield, pure oil, no filtration
(2) The oil is squeezed once, the speed is fast, and the labor intensity is small
(3) Electromechanical integrated design, small footprint and easy operation
(4) Fast purification, stable and durable performance
This machine can be used for process many kinds of raw material: sesame, walnut kernel, peanut, pine seed (better to get rid of the shell), almond, spricot kernel, perilla, cocoa bean, linseed, avocado and other oil crops.
1. You can choose the model that suits you according to your requirements.
2. If you need other models, we can also customize it for you.
| Model | 6YY-185 | 6YY-230(A) | 6YY-230(B) | 6YY-250 | 6YY-270 | 6YY-300 | 6YY-335 | 6YY-355 |
| Capacity | 4(kg/batch) | 8.5(kg/batch) | 9.5(kg/batch) | 11(kg/batch) | 13.5(kg/batch) | 16(kg/batch) | 20(kg/batch) | 23(kg/batch) |
| Weight(kg) | 590(kg) | 924(kg) | 970(kg) | 1070(kg) | 1230(kg) | 1600(kg) | 1750(kg) | 2350v |
| Working pressure | 60Mpa | 60Mpa | 60Mpa | 60Mpa | 60Mpa | 60Mpa | 60Mpa | 60Mpa |
| Power(single/3 phase) | 2.2/1.1kw | 2.2/1.1kw | 2.2/1.1kw | 2.2/1.1kw | 4.0/2.2kw | 4.8/2.2kw | 4.8/2.2kw | 5.0/3.0kw |
| Dimension(mm) | 600*880*1150 | 670*950*1460 | 670*950*1560 | 710*950*1560 | 750*1010*1660 | 1000*1100*1160 | 1100*1240*1730 | 1160*1200*1810 |
| Oil cake diameter | 185mm | 230mm | 230mm | 250mm | 270mm | 300mm | 335mm | 355mm |
| Residual oil rate | ≤2 | ≤2 | ≤2 | ≤2 | ≤2 | ≤2 | ≤2 | ≤2 |
Sesame oil extraction process:
The design is scientific, the structure is reasonable, the operation is simple, the safety is stable, and the fully automated device is used. It takes only a few minutes from the feeding to the finished product.
Since 1998. Henan Lewin Industrial Development Co Ltd was found offcially registered under Henan companies.It is a firm which has the ability for manufacture,Research& Development.Our main products are hydraulic oil press machine,spiral oil press machine,the accessory equipment for the oil press machine and other machines.
1). The equipment guarantee period is one year, During guarantee period, the seller will provide maintenance free service.(Except the breakdown and destroy caused by person and force majeure)
2). After receiving the inquiry for repairing the engineer of sell party will solve by phone and email, if necessary the engineer will go to solve the problem on the spot, the buyer should pay daily salary $100, also pay technical visa cost, round trip tickets, rooms and meals.
3). During the quality guarantee period, if it is the quality problem (except easily damaged parts), the cost for maintenance and replace will be borne by sellers.
4). During guarantee period, the seller will provide service of with compensation as follows:
(1)The damage caused by person and force majeure;
(2)The damage caused by improper operating;
(3)The damage caused by reforming, decomposing assembling.
5). Paid service will be provided for the long term after guarantee period.
1. Standard export wooden case package.
2. Customized.
Delivery:
Generally 7-10 working days after receipt the deposit.
Q: When can I get the price?
A: We usually quote within 24 hours after we get your inquiry.If you are very urgent to get the price, please call us or tell us in your email so that we will regard your inquiry priority.
Q: I don't know how to use the oil press machine.
A: Don't worry, we will send you Manual for oil press machine. We also provide the operation videos of oil press machine.
Q: Can you guarantee your quality?
A: Of course. We are the manufacture factory. Best quality is our principle all the time.
